DH137SE
Product Comparison
Parameters
Commencement
| Model Number | DH137SE |
| Cutting Width | 137/53.94 cm/inches |
| Cutting Height | 21/8.27 cm/inches |
| Cutting Length | 173/68.11 cm/inches |
| Mains Power | 5.5 kw |
| Net Weight | 4800/10560 kg/lbs |
| Machine Width | 337/132.68 cm/inches (with side tables) 299.5/117.91 cm/inches (without side tables) |
| Machine Length | 318.5/125.40 cm/inches |
| Machine Height | 180/70.87 cm/inches |
| Length Of Front Table | 75.5/29.72 cm/inches |
| Desktop Height | 90/35.43 cm/inches |
| Minimum Platen Pressure | 200/440 dan/lbs |
| Maximum Platen Pressure | 4500/9900 dan/lbs |
| Blade Specification (L*W*H) | 13.75*160*1630/0.54*6.3*64.17 mm |
| Maximum Sharpenable Area | 6/2.36 cm/inches |
| Minimum Cutting | 2.5/1 cm/inches (without lever) 9.5/3.74 cm/inches (with lever) |
| Cutting Speed | 45 times/min |
| Package Size (L*W*H) | 360*160*210/141.73*62.99*82.68 cm |
| Supply Voltage | 361-399 V |
| Wire Thickness | 4 ㎡ |
| Feeding Speed |
Commencement
| Machine Profile Length | |
| Machine Profile Width | |
| High Machine Profile | |
| Machine Foundation Length | |
| Machine Foundation Width | |
| Machine Foundation Thickness | |
| Fuselage Half-Width | |
| Net Weight | |
| Package Size |
