QS-4 Intelligent Paper Picker

QS-4

Product Comparison

Product Overview

Intelligent paper picker (QS-4)

The programmable pick-up height maximizes the guarantee of non-destruction of paper according to the paper quality.

Newly adjusted movement of the pick-up roller maximizes the guarantee of non-destruction of paper. Quickly replaceable paper picking roller, greatly improving the efficiency of equipment maintenance.

The working platform is equipped with a blowing structure to facilitate the movement of paper, pneumatic manipulator safety clamping device to realize flexible paper clamping, to protect the corners of the paper from external forces curling deformation.

Contact Us

Parameters

Machine Parameter:QS-4

Commencement

Model Number QS-4
Minimum Format (Y) 600 mm
Minimum Format (X) 850 mm
Maximum Format (Y) 1300,1250 mm
Maximum Format (X) 1680 mm
Minimum Height Per Order 55 mm
Maximum Per-ring Height 165 mm
Maximum Stacking Height 1600 mm
Dead Weight 480 kg
Unloading Time 40-55 S
Noise Level 75 dB
Maximum Inner Platform Size (Y)
Maximum Size Of Inner Platform (X)
Maximum Stroke (Stack Height)
Maximum Loading Capacity
Noise Level (EN13023)
Package Size
Size Of Table Plate (A)
Table Plate Size (B)
Unwind Height
Table Height
Mounting Parameters:QS-4

Commencement

Machine Width 4450 mm
Machine Depth 2560 mm
Machine Height 2640 mm
Net Weight 2500 kg
Compressed Air 5-8 bar
Gas Consumption 4 L/Min
Power Consumption (Max) 8 KW
Maximum Fuse Current 20 A
Supply Voltage 380±5%V/50HZ
Package Size 2540*3500*2867 mm
Height At Maximum Stroke
