Brand new veneers for unmatched durability

GS-4 Intelligent Paper Unloader

GS-4

Product Comparison

Product Overview

Intelligent Paper Unloader (GS-4)

The machine is equipped with automatic paper stack pick-up and loading function, which can quickly and automatically transfer the paper in the stack to the working platform.

Infrared position detection device, accurately detects the position of the paper to ensure that the paper is stacked neatly.

Anti-collision flexible bumper, effectively preventing accidental collision during machine movement.

Pneumatic manipulator safety clamping device, to realize flexible paper clamping, to protect the corners of the paper from external force curling deformation.

Contact Us

Parameters

Machine Parameter:GS-4

Commencement

Model Number GS-4
Minimum Format (Y) 500 mm
Minimum Format (X) 500 mm
Maximum Format (Y) 1240 mm
Maximum Format (X) 1650 mm
Minimum Height Per Order 40 mm
Maximum Per-ring Height 165 mm
Maximum Stacking Height 1600 mm
Dead Weight 420 kg
Unloading Time 30-40 S
Noise Level 75 dB
Maximum Inner Platform Size (Y)
Maximum Size Of Inner Platform (X)
Maximum Stroke (Stack Height)
Maximum Loading Capacity
Noise Level (EN13023)
Package Size
Size Of Table Plate (A)
Table Plate Size (B)
Unwind Height
Table Height
Mounting Parameters:GS-4

Commencement

Machine Width 4000 mm
Machine Depth 2290 mm
Machine Height 2640 mm
Net Weight 2800 kg
Compressed Air 5-8 bar
Gas Consumption 6 L/Min
Power Consumption (Max) 8 KW
Maximum Fuse Current 20 A
Supply Voltage 380±5%V/50HZ
Package Size 4200*2450*3960 mm
Height At Maximum Stroke
